RT9059-15GQW

Richtek USA Inc.

Manufacturer

Richtek USA Inc.

Description:

IC LDO 3A LOW DROPOUT WDFN-10

Datasheet:

RT9059-15GQW Datasheet

$0.69

Available to order

Reference Price (USD)

$0.69000

500+

$0.6831

1000+

$0.6762

1500+

$0.6693

2000+

$0.6624

2500+

$0.6555

Exquisite packaging

Discount

TT / Paypal / Credit Card / Western Union / Money Gram

The RT9059-15GQW from Richtek USA Inc. is a high-performance linear voltage regulator IC designed for precision power management applications. As part of our PMIC - Voltage Regulators - Linear collection, this component offers exceptional voltage regulation with low dropout characteristics. Featuring thermal shutdown protection and current limiting, this IC maintains stable output voltage even under varying load conditions. These linear regulators are ideal for noise-sensitive applications requiring clean power delivery, such as medical devices, audio equipment, and precision measurement instruments. Typical implementations include power conditioning for microcontroller systems, battery-powered devices, and as post-regulators for switching power supplies.

Specifications

Product Status: Active
Output Configuration: Positive
Output Type: Fixed
Number of Regulators: 1
Voltage - Input (Max): 5.5V
Voltage - Output (Min/Fixed): 1.5V
Voltage - Output (Max): -
Voltage Dropout (Max): 0.45V @ 3A
Current - Output: 3A
Current - Quiescent (Iq): 1.2 mA
Current - Supply (Max): -
PSRR: -
Control Features: Enable, Power Good, Soft Start
Protection Features: Over Current, Over Temperature, Short Circuit, Under Voltage Lockout (UVLO)
Operating Temperature: -40°C ~ 85°C (TA)
Mounting Type: Surface Mount
Package / Case: 10-WFDFN Exposed Pad
Supplier Device Package: 10-WDFN (3x3)
