SFM-135-01-S-D-LC

Samtec Inc.

Manufacturer

Samtec Inc.

Description:

CONN RCPT 70POS 0.05 GOLD PCB

Datasheet:

SFM-135-01-S-D-LC Datasheet

$20.36

Available to order

Reference Price (USD)

$10.76000

Exquisite packaging

Discount

TT / Paypal / Credit Card / Western Union / Money Gram

The SFM-135-01-S-D-LC Samtec Inc. Rectangular Connectors - Headers, Receptacles, and Female Sockets are engineered for high-performance applications requiring stable and durable connections. Featuring temperature-resistant materials and vibration-proof designs, these connectors are perfect for automotive electronics, power supplies, and HVAC systems. Their versatility extends to EV charging stations, uninterruptible power supplies, and building automation. Trust Samtec Inc. for connectors that combine innovation with reliability.

Specifications

Product Status: Active
Connector Type: Receptacle
Contact Type: Female Socket
Style: Board to Board or Cable
Number of Positions: 70
Number of Positions Loaded: All
Pitch - Mating: 0.050" (1.27mm)
Number of Rows: 2
Row Spacing - Mating: 0.050" (1.27mm)
Mounting Type: Through Hole
Termination: Solder
Fastening Type: Push-Pull
Contact Finish - Mating: Gold
Contact Finish Thickness - Mating: 30.0µin (0.76µm)
Insulation Color: Black
Insulation Height: 0.180" (4.57mm)
Contact Length - Post: 0.120" (3.05mm)
Operating Temperature: -55°C ~ 125°C
Material Flammability Rating: UL94 V-0
Contact Finish - Post: Tin
Mated Stacking Heights: 6.02mm, 6.17mm, 7.80mm, 7.95mm, 9.58mm, 9.73mm, 11.48mm, 11.63mm
Ingress Protection: -
Features: Board Lock
Current Rating (Amps): 3.2A per Contact
Voltage Rating: 250VAC
