SMBJ4747E3/TR13
Microchip Technology
Microchip Technology
DIODE ZENER 20V 2W SMBJ
$0.42
Available to order
Reference Price (USD)
3,000+
$0.33350
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Discover the SMBJ4747E3/TR13 Zener diode by Microchip Technology, a standout in the Discrete Semiconductor Products lineup. This single Zener diode is engineered for precise voltage regulation, featuring a robust design that ensures long-term durability. With its low leakage current and high surge capability, the SMBJ4747E3/TR13 is perfect for critical applications. Typical uses include voltage stabilization in consumer electronics, such as TVs and audio equipment, as well as in medical devices where consistent performance is paramount. The SMBJ4747E3/TR13 is also a preferred choice for circuit protection in renewable energy systems, safeguarding inverters and charge controllers from voltage fluctuations.
Specifications
- Product Status: Active
- Voltage - Zener (Nom) (Vz): 20 V
- Tolerance: ±10%
- Power - Max: 2 W
- Impedance (Max) (Zzt): 22 Ohms
- Current - Reverse Leakage @ Vr: 5 µA @ 15.2 V
- Voltage - Forward (Vf) (Max) @ If: 1.2 V @ 200 mA
- Operating Temperature: -65°C ~ 150°C
- Mounting Type: Surface Mount
- Package / Case: DO-214AA, SMB
- Supplier Device Package: SMBJ (DO-214AA)
