SMDJ22AHR7G
Taiwan Semiconductor Corporation
Taiwan Semiconductor Corporation
TVS DIODE 22VWM 35.5VC DO214AB
$0.00
Available to order
Reference Price (USD)
1,700+
$0.46136
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Discover the SMDJ22AHR7G TVS diode from Taiwan Semiconductor Corporation, a key component for effective circuit protection. This diode features low clamping voltage and high energy dissipation, making it suitable for sensitive applications. TVS diodes are widely employed in automotive electronics, industrial controls, and telecommunications. They provide critical protection against ESD and other transient threats. For example, the SMDJ22AHR7G can defend automotive infotainment systems from voltage spikes. Taiwan Semiconductor Corporation is your trusted source for high-quality TVS diodes that ensure device longevity and performance.
Specifications
- Product Status: Discontinued at Digi-Key
- Type: Zener
- Unidirectional Channels: 1
- Bidirectional Channels: -
- Voltage - Reverse Standoff (Typ): 22V
- Voltage - Breakdown (Min): 24.4V
- Voltage - Clamping (Max) @ Ipp: 35.5V
- Current - Peak Pulse (10/1000µs): 84.5A
- Power - Peak Pulse: 3000W (3kW)
- Power Line Protection: No
- Applications: Automotive
- Capacitance @ Frequency: -
- Operating Temperature: -55°C ~ 175°C (TJ)
- Mounting Type: Surface Mount
- Package / Case: DO-214AB, SMC
- Supplier Device Package: DO-214AB (SMC)
