SN74HC03N
Texas Instruments
Texas Instruments
IC GATE NAND OD 4CH 2-INP 14DIP
$0.60
Available to order
Reference Price (USD)
1+
$0.40000
10+
$0.34500
25+
$0.32200
100+
$0.25760
500+
$0.20240
1,000+
$0.15640
2,500+
$0.14260
5,000+
$0.13340
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The SN74HC03N from Texas Instruments delivers exceptional value in the Logic - Gates and Inverters market segment. This surface-mount IC combines multiple universal logic gates with optimized power-speed performance ratios. Key benefits include latch-up immunity exceeding 500mA and input leakage current below 1 A. Design engineers implement this component in power management systems, digital control circuits, and signal processing applications. Specific use cases include solar inverter controls, elevator logic boards, and industrial sensor networks. The SN74HC03N's compatibility with automated pick-and-place manufacturing processes makes it an economical choice for high-volume production runs across consumer and industrial sectors.
Specifications
- Product Status: Active
- Logic Type: NAND Gate
- Number of Circuits: 4
- Number of Inputs: 2
- Features: Open Drain
- Voltage - Supply: 2V ~ 6V
- Current - Quiescent (Max): 2 µA
- Current - Output High, Low: -, 5.2mA
- Logic Level - Low: 0.5V ~ 1.8V
- Logic Level - High: 1.5V ~ 4.2V
- Max Propagation Delay @ V, Max CL: 23ns @ 6V, 50pF
- Operating Temperature: -40°C ~ 85°C
- Mounting Type: Through Hole
- Supplier Device Package: 14-PDIP
- Package / Case: 14-DIP (0.300", 7.62mm)
