SN74LS05D
onsemi
onsemi
IC INVERTER OPEN 6CH 1-IN 14SOIC
$0.53
Available to order
Reference Price (USD)
1+
$0.53000
500+
$0.5247
1000+
$0.5194
1500+
$0.5141
2000+
$0.5088
2500+
$0.5035
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The SN74LS05D from onsemi delivers exceptional value in the Logic - Gates and Inverters market segment. This surface-mount IC combines multiple universal logic gates with optimized power-speed performance ratios. Key benefits include latch-up immunity exceeding 500mA and input leakage current below 1 A. Design engineers implement this component in power management systems, digital control circuits, and signal processing applications. Specific use cases include solar inverter controls, elevator logic boards, and industrial sensor networks. The SN74LS05D's compatibility with automated pick-and-place manufacturing processes makes it an economical choice for high-volume production runs across consumer and industrial sectors.
Specifications
- Product Status: Obsolete
- Logic Type: Inverter
- Number of Circuits: 6
- Number of Inputs: 1
- Features: Open Collector
- Voltage - Supply: 4.75V ~ 5.25V
- Current - Quiescent (Max): -
- Current - Output High, Low: -, 8mA
- Logic Level - Low: 0.8V
- Logic Level - High: 2V
- Max Propagation Delay @ V, Max CL: 32ns @ 5V, 15pF
- Operating Temperature: 0°C ~ 70°C
- Mounting Type: Surface Mount
- Supplier Device Package: 14-SOIC
- Package / Case: 14-SOIC (0.154", 3.90mm Width)
