SN74LS109AD
Texas Instruments

Texas Instruments
IC FF JK TYPE DUAL 1BIT 16SOIC
$1.60
Available to order
Reference Price (USD)
1+
$1.60000
500+
$1.584
1000+
$1.568
1500+
$1.552
2000+
$1.536
2500+
$1.52
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The SN74LS109AD Flip Flop by Texas Instruments is a must-have in the Logic - Flip Flops category of Integrated Circuits (ICs). Designed for high-performance digital systems, this flip flop offers fast switching speeds and excellent power efficiency. It's widely used in networking equipment, servers, and data centers, ensuring seamless data flow. The SN74LS109AD is also a favorite in renewable energy systems, where reliability is paramount. Trust Texas Instruments to deliver top-quality flip flops that meet your technical requirements.
Specifications
- Product Status: Active
- Function: Set(Preset) and Reset
- Type: JK Type
- Output Type: Complementary
- Number of Elements: 2
- Number of Bits per Element: 1
- Clock Frequency: 33 MHz
- Max Propagation Delay @ V, Max CL: 40ns @ 5V, 15pF
- Trigger Type: Positive Edge
- Current - Output High, Low: 400µA, 8mA
- Voltage - Supply: 4.75V ~ 5.25V
- Current - Quiescent (Iq): 8 mA
- Input Capacitance: -
- Operating Temperature: 0°C ~ 70°C (TA)
- Mounting Type: Surface Mount
- Supplier Device Package: 16-SOIC
- Package / Case: 16-SOIC (0.154", 3.90mm Width)
