STPS20L60CGY-TR
STMicroelectronics
STMicroelectronics
DIODE ARRAY SCHOTTKY 60V D2PAK
$3.10
Available to order
Reference Price (USD)
1,000+
$1.44320
2,000+
$1.39920
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The STPS20L60CGY-TR rectifier array from STMicroelectronics redefines efficiency in the Diodes - Rectifiers - Arrays classification. Its optimized chip geometry enables higher surge withstand capability, critical for automotive alternators and arc suppression circuits. This product shines in three-phase rectification and snubber networks, offering aerospace-grade reliability. STMicroelectronics's precision manufacturing ensures each STPS20L60CGY-TR meets stringent quality standards for mission-critical applications.
Specifications
- Product Status: Active
- Diode Configuration: 1 Pair Common Cathode
- Diode Type: Schottky
- Voltage - DC Reverse (Vr) (Max): 60 V
- Current - Average Rectified (Io) (per Diode): 10A
- Voltage - Forward (Vf) (Max) @ If: 600 mV @ 10 A
- Speed: Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr): -
- Current - Reverse Leakage @ Vr: 350 µA @ 60 V
- Operating Temperature - Junction: -40°C ~ 175°C
- Mounting Type: Surface Mount
- Package / Case: TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
- Supplier Device Package: D²PAK
