STS2DPFS20V
STMicroelectronics
STMicroelectronics
MOSFET P-CH 20V 2.5A 8SO
$0.00
Available to order
Reference Price (USD)
2,500+
$0.89100
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Meet the STS2DPFS20V by STMicroelectronics, a high-efficiency single MOSFET engineered for superior performance in the Discrete Semiconductor Products arena. Featuring low gate drive requirements and high switching frequency, this component is perfect for RF applications, power tools, and HVAC systems. The STS2DPFS20V stands out in the Transistors - FETs, MOSFETs - Single category for its rugged design and consistent output. Choose quality, choose STMicroelectronics.
Specifications
- Product Status: Obsolete
- FET Type: P-Channel
- Technology: MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss): 20 V
- Current - Continuous Drain (Id) @ 25°C: 2.5A (Tc)
- Drive Voltage (Max Rds On, Min Rds On): 2.7V, 4.5V
- Rds On (Max) @ Id, Vgs: 200mOhm @ 1A, 4.5V
- Vgs(th) (Max) @ Id: 600mV @ 250µA (Min)
- Gate Charge (Qg) (Max) @ Vgs: 4.7 nC @ 4.5 V
- Vgs (Max): ±12V
- Input Capacitance (Ciss) (Max) @ Vds: 315 pF @ 15 V
- FET Feature: Schottky Diode (Isolated)
- Power Dissipation (Max): 2W (Tc)
- Operating Temperature: 150°C (TJ)
- Mounting Type: Surface Mount
- Supplier Device Package: 8-SOIC
- Package / Case: 8-SOIC (0.154", 3.90mm Width)
