STSJ100NH3LL
STMicroelectronics
STMicroelectronics
MOSFET N-CH 30V 100A 8SOIC
$0.00
Available to order
Reference Price (USD)
2,500+
$1.11375
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Meet the STSJ100NH3LL by STMicroelectronics, a high-efficiency single MOSFET engineered for superior performance in the Discrete Semiconductor Products arena. Featuring low gate drive requirements and high switching frequency, this component is perfect for RF applications, power tools, and HVAC systems. The STSJ100NH3LL stands out in the Transistors - FETs, MOSFETs - Single category for its rugged design and consistent output. Choose quality, choose STMicroelectronics.
Specifications
- Product Status: Obsolete
- FET Type: N-Channel
- Technology: MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss): 30 V
- Current - Continuous Drain (Id) @ 25°C: 100A (Tc)
- Drive Voltage (Max Rds On, Min Rds On): 4.5V, 10V
- Rds On (Max) @ Id, Vgs: 3.5mOhm @ 12.5A, 10V
- Vgs(th) (Max) @ Id: 1V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs: 40 nC @ 4.5 V
- Vgs (Max): ±16V
- Input Capacitance (Ciss) (Max) @ Vds: 4450 pF @ 25 V
- FET Feature: -
- Power Dissipation (Max): 3W (Ta), 70W (Tc)
- Operating Temperature: 150°C (TJ)
- Mounting Type: Surface Mount
- Supplier Device Package: 8-SOIC-EP
- Package / Case: 8-SOIC (0.154", 3.90mm Width) Exposed Pad
