TC7SH09F,LJ(CT
Toshiba Semiconductor and Storage
Toshiba Semiconductor and Storage
IC GATE AND OD 1CH 2-INP SMV
$0.07
Available to order
Reference Price (USD)
3,000+
$0.07000
6,000+
$0.06300
15,000+
$0.05600
30,000+
$0.05250
75,000+
$0.04655
150,000+
$0.04480
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The TC7SH09F,LJ(CT by Toshiba Semiconductor and Storage sets new standards in the Logic - Gates and Inverters category of Integrated Circuits. Featuring advanced silicon-gate CMOS technology, this IC delivers superior performance in logic level conversion and signal gating applications. Notable characteristics include symmetrical output drive capability, balanced propagation delays, and 3-state outputs for bus-oriented applications. Electronic designers frequently incorporate this component in data acquisition systems, test equipment, and digital displays. Practical applications range from factory automation to renewable energy systems and telecommunications infrastructure. The TC7SH09F,LJ(CT's EMC compliance ensures trouble-free integration into complex electronic systems.
Specifications
- Product Status: Active
- Logic Type: AND Gate
- Number of Circuits: 1
- Number of Inputs: 2
- Features: Open Drain
- Voltage - Supply: 2V ~ 5.5V
- Current - Quiescent (Max): 2 µA
- Current - Output High, Low: -, 8mA
- Logic Level - Low: 0.5V ~ 1.65V
- Logic Level - High: 1.5V ~ 3.85V
- Max Propagation Delay @ V, Max CL: 7.5ns @ 5V, 50pF
- Operating Temperature: -40°C ~ 85°C
- Mounting Type: Surface Mount
- Supplier Device Package: SMV
- Package / Case: SC-74A, SOT-753
