TK20V60W,LVQ
Toshiba Semiconductor and Storage
Toshiba Semiconductor and Storage
MOSFET N-CH 600V 20A 4DFN
$2.83
Available to order
Reference Price (USD)
2,500+
$2.63900
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The TK20V60W,LVQ single MOSFET from Toshiba Semiconductor and Storage is a game-changer in power electronics. As part of the Discrete Semiconductor Products family, it offers unparalleled efficiency in energy conversion and management. Key applications include uninterruptible power supplies (UPS), welding equipment, and industrial motor drives. With features like high temperature operation and ESD protection, the TK20V60W,LVQ is a must-have in the Transistors - FETs, MOSFETs - Single category.
Specifications
- Product Status: Active
- FET Type: N-Channel
- Technology: MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss): 600 V
- Current - Continuous Drain (Id) @ 25°C: 20A (Ta)
- Drive Voltage (Max Rds On, Min Rds On): 10V
- Rds On (Max) @ Id, Vgs: 170mOhm @ 10A, 10V
- Vgs(th) (Max) @ Id: 3.7V @ 1mA
- Gate Charge (Qg) (Max) @ Vgs: 48 nC @ 10 V
- Vgs (Max): ±30V
- Input Capacitance (Ciss) (Max) @ Vds: 1680 pF @ 300 V
- FET Feature: Super Junction
- Power Dissipation (Max): 156W (Tc)
- Operating Temperature: 150°C (TJ)
- Mounting Type: Surface Mount
- Supplier Device Package: 4-DFN-EP (8x8)
- Package / Case: 4-VSFN Exposed Pad
