TLV70015DCKT

Texas Instruments

Manufacturer

Texas Instruments

Description:

IC REG LINEAR 1.5V 200MA SC70-5

Datasheet:

TLV70015DCKT Datasheet

$1.08

Available to order

Reference Price (USD)

$1.08000

500+

$1.0692

1000+

$1.0584

1500+

$1.0476

2000+

$1.0368

2500+

$1.026

Exquisite packaging

Discount

TT / Paypal / Credit Card / Western Union / Money Gram

The TLV70015DCKT from Texas Instruments is a high-performance linear voltage regulator IC designed for precision power management applications. As part of our PMIC - Voltage Regulators - Linear collection, this component offers exceptional voltage regulation with low dropout characteristics. Featuring thermal shutdown protection and current limiting, this IC maintains stable output voltage even under varying load conditions. These linear regulators are ideal for noise-sensitive applications requiring clean power delivery, such as medical devices, audio equipment, and precision measurement instruments. Typical implementations include power conditioning for microcontroller systems, battery-powered devices, and as post-regulators for switching power supplies.

Specifications

Product Status: Active
Output Configuration: Positive
Output Type: Fixed
Number of Regulators: 1
Voltage - Input (Max): 5.5V
Voltage - Output (Min/Fixed): 1.5V
Voltage - Output (Max): -
Voltage Dropout (Max): 0.25V @ 200mA
Current - Output: 200mA
Current - Quiescent (Iq): 55 µA
Current - Supply (Max): 270 µA
PSRR: 68dB (1kHz)
Control Features: Enable
Protection Features: Over Current, Over Temperature, Reverse Polarity, Under Voltage Lockout (UVLO)
Operating Temperature: -40°C ~ 125°C (TJ)
Mounting Type: Surface Mount
Package / Case: 5-TSSOP, SC-70-5, SOT-353
Supplier Device Package: SC-70-5
