TN22-1500H
STMicroelectronics
STMicroelectronics
SCR 400V 2A IPAK
$1.66
Available to order
Reference Price (USD)
1+
$1.59000
75+
$1.35240
150+
$1.11093
525+
$0.91770
1,050+
$0.72450
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Introducing the TN22-1500H SCR by STMicroelectronics, a high-reliability component in the Thyristors family of Discrete Semiconductor Products. Its notable features include precise gate control and excellent thermal cycling performance. Widely adopted in traction systems, welding inverters, and power distribution networks, this thyristor demonstrates exceptional versatility. STMicroelectronics's TN22-1500H is the smart choice for engineers seeking robust power control solutions.
Specifications
- Product Status: Active
- Voltage - Off State: 400 V
- Voltage - Gate Trigger (Vgt) (Max): 3 V
- Current - Gate Trigger (Igt) (Max): 1.5 mA
- Voltage - On State (Vtm) (Max): 3.1 V
- Current - On State (It (AV)) (Max): 1.8 A
- Current - On State (It (RMS)) (Max): 2 A
- Current - Hold (Ih) (Max): 175 mA
- Current - Off State (Max): 100 µA
- Current - Non Rep. Surge 50, 60Hz (Itsm): 20A, 22A
- SCR Type: Standard Recovery
- Operating Temperature: -40°C ~ 110°C
- Mounting Type: Through Hole
- Package / Case: TO-251-3 Short Leads, IPak, TO-251AA
- Supplier Device Package: TO-251 (IPAK)
