TPS70845PWPG4

Texas Instruments

Manufacturer

Texas Instruments

Description:

IC REG LINEAR 3.3V/1.2V 20HTSSOP

Datasheet:

TPS70845PWPG4 Datasheet

$0.00

Available to order

Reference Price (USD)

210+

$2.84505

Exquisite packaging

Discount

TT / Paypal / Credit Card / Western Union / Money Gram

Discover the TPS70845PWPG4, a premium PMIC - Voltage Regulators - Linear IC from Texas Instruments, engineered to provide exceptional voltage regulation with minimal power loss. This IC is part of the esteemed PMIC - Voltage Regulators - Linear category, known for its ability to maintain stable voltage levels under varying load conditions. The TPS70845PWPG4 excels with its low quiescent current, high efficiency, and superior thermal management, ensuring optimal performance in demanding environments. Linear voltage regulators like the TPS70845PWPG4 are pivotal in applications requiring precise voltage control without the complexity of switching regulators. The TPS70845PWPG4 offers outstanding line and load regulation, making it a preferred choice for sensitive electronic circuits. Its advanced protection features, including over-current and over-temperature safeguards, further enhance its reliability. The TPS70845PWPG4 finds applications across multiple sectors, including medical devices, industrial automation, and consumer electronics. For example, it is used in wearable health monitors, factory automation systems, and smart home devices. Its ability to deliver clean and stable power makes it indispensable for modern electronic designs, ensuring both performance and safety.

Specifications

Product Status: Discontinued at Digi-Key
Output Configuration: Positive
Output Type: Fixed
Number of Regulators: 2
Voltage - Input (Max): 6V
Voltage - Output (Min/Fixed): 3.3V, 1.2V
Voltage - Output (Max): -
Voltage Dropout (Max): 0.14V @ 250mA, -
Current - Output: 250mA, 125mA
Current - Quiescent (Iq): 230 µA
Current - Supply (Max): -
PSRR: 60dB (1KHz), 50dB (1kHz)
Control Features: Enable, Power Good, Reset, Sequencing
Protection Features: Over Current, Over Temperature, Reverse Polarity, Under Voltage Lockout (UVLO)
Operating Temperature: -40°C ~ 125°C
Mounting Type: Surface Mount
Package / Case: 20-PowerTSSOP (0.173", 4.40mm Width)
Supplier Device Package: 20-HTSSOP
