TPS74301RGWTG4

Texas Instruments

Manufacturer

Texas Instruments

Description:

IC REG LIN POS ADJ 1.5A 20VQFN

Datasheet:

TPS74301RGWTG4 Datasheet

$0.00

Available to order

Reference Price (USD)

$0.00000

500+

1000+

1500+

2000+

2500+

Exquisite packaging

Discount

TT / Paypal / Credit Card / Western Union / Money Gram

Optimize your power management with the TPS74301RGWTG4, a premium PMIC - Voltage Regulators - Linear IC from Texas Instruments. This IC delivers precise voltage regulation, ensuring optimal performance for your electronic circuits. With features like low dropout voltage, high output current, and excellent thermal stability, the TPS74301RGWTG4 is designed to excel in the most demanding applications. PMIC - Voltage Regulators - Linear ICs are vital for maintaining voltage integrity, and the TPS74301RGWTG4 is a prime example of this technology. It offers superior noise rejection and fast response times, making it ideal for sensitive applications. Its compact size and high efficiency also make it suitable for space-constrained designs. The TPS74301RGWTG4 is used in a variety of industries, including automotive, telecommunications, and industrial automation. For example, it is found in electric vehicle power systems, 5G infrastructure, and programmable logic controllers (PLCs). Its reliability and performance make it a trusted choice for engineers worldwide.

Specifications

Product Status: Discontinued at Digi-Key
Output Configuration: Positive
Output Type: Adjustable
Number of Regulators: 1
Voltage - Input (Max): 5.5V
Voltage - Output (Min/Fixed): 0.8V
Voltage - Output (Max): 3.6V
Voltage Dropout (Max): 0.12V @ 1.5A
Current - Output: 1.5A
Current - Quiescent (Iq): 115 µA
Current - Supply (Max): 1.5 mA
PSRR: 73dB ~ 42dB (1kHz ~ 800kHz)
Control Features: Enable, Power Good, Tracking
Protection Features: Over Current, Over Temperature, Short Circuit, Under Voltage Lockout (UVLO)
Operating Temperature: -40°C ~ 125°C
Mounting Type: Surface Mount
Package / Case: 20-VQFN Exposed Pad
Supplier Device Package: 20-VQFN (5x5)
