TS5A22362DGSR
Texas Instruments

Texas Instruments
IC SWITCH SPDT DUAL 10VSSOP
$1.25
Available to order
Reference Price (USD)
2,500+
$0.55440
5,000+
$0.52668
12,500+
$0.50688
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Engineered for mission-critical switching applications, the TS5A22362DGSR by Texas Instruments delivers unmatched reliability in our Analog Interface ICs portfolio. Its monolithic CMOS construction provides <5pF channel capacitance and rail-to-rail signal handling capability. The TS5A22362DGSR excels in aerospace telemetry systems, downhole drilling instrumentation, and renewable energy inverters where vibration resistance and long-term stability are paramount. Unique features include: power-off protection (signals pass when unpowered), TTL/CMOS compatible control inputs, and daisy-chain capability for channel expansion. Sample applications include: multi-zone HVAC controls, spectrometer detector arrays, and autonomous vehicle LIDAR subsystems.
Specifications
- Product Status: Active
- Switch Circuit: SPDT
- Multiplexer/Demultiplexer Circuit: 2:1
- Number of Circuits: 2
- On-State Resistance (Max): 740mOhm
- Channel-to-Channel Matching (ΔRon): 40mOhm
- Voltage - Supply, Single (V+): 2.3V ~ 5.5V
- Voltage - Supply, Dual (V±): -
- Switch Time (Ton, Toff) (Max): 80ns, 70ns
- -3db Bandwidth: 18.3MHz
- Charge Injection: 10pC
- Channel Capacitance (CS(off), CD(off)): 70pF
- Current - Leakage (IS(off)) (Max): 50nA
- Crosstalk: -78dB @ 100kHz
- Operating Temperature: -40°C ~ 85°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 10-TFSOP, 10-MSOP (0.118", 3.00mm Width)
- Supplier Device Package: 10-VSSOP
