U6815BM-NFL
Microchip Technology
Microchip Technology
IC PWR DRIVER N/P-CHAN 0.05 28SO
$0.00
Available to order
Reference Price (USD)
1+
$0.00000
500+
$0
1000+
$0
1500+
$0
2000+
$0
2500+
$0
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The U6815BM-NFL Load Driver IC by Microchip Technology is a versatile solution for modern power distribution challenges. Part of the PMIC family, this IC provides precise load driving capabilities with built-in safeguards like short-circuit and overvoltage protection. From smart home appliances to medical equipment, the U6815BM-NFL delivers consistent performance. Its compact design and energy-saving features make it a favorite among engineers. Choose Microchip Technology for ICs that combine power, precision, and protection in one advanced package.
Specifications
- Product Status: Obsolete
- Switch Type: General Purpose
- Number of Outputs: 12
- Ratio - Input:Output: 1:12
- Output Configuration: High Side or Low Side
- Output Type: N/P-Channel
- Interface: SPI
- Voltage - Load: 40V (Max)
- Voltage - Supply (Vcc/Vdd): 4.5V ~ 5.5V
- Current - Output (Max): 600mA
- Rds On (Typ): 2Ohm (Max), 1.5Ohm (Max)
- Input Type: -
- Features: -
- Fault Protection: Current Limiting (Fixed), Open Load Detect, Over Temperature, Over Voltage
- Operating Temperature: -40°C ~ 150°C (TJ)
- Mounting Type: Surface Mount
- Supplier Device Package: 28-SO
- Package / Case: 28-SOIC (0.295", 7.50mm Width)
