UC2823AN

Texas Instruments

Manufacturer

Texas Instruments

Description:

IC REG CTRLR MULT TOPOLOGY 16DIP

Datasheet:

UC2823AN Datasheet

$29.93

Available to order

Reference Price (USD)

$20.18000

10+

$18.54300

25+

$17.77480

100+

$15.66100

500+

$13.93160

Exquisite packaging

Discount

TT / Paypal / Credit Card / Western Union / Money Gram

The UC2823AN from Texas Instruments is a cutting-edge DC DC Switching Controller designed for the PMIC - Voltage Regulators segment. With features like programmable frequency, over-current protection, and high efficiency, this IC is ideal for use in telecommunications, automotive, and industrial applications. Examples include base stations, electric vehicle charging systems, and factory automation equipment. Texas Instruments's UC2823AN stands out for its reliability and performance, ensuring seamless power conversion in any environment.

Specifications

Product Status: Active
Output Type: Transistor Driver
Function: Step-Up, Step-Up/Step-Down
Output Configuration: Positive
Topology: Boost, Flyback, Forward Converter, Full-Bridge, Half-Bridge, Push-Pull
Number of Outputs: 1
Output Phases: 1
Voltage - Supply (Vcc/Vdd): 8.4V ~ 22V
Frequency - Switching: 400kHz ~ 1MHz
Duty Cycle (Max): 100%
Synchronous Rectifier: No
Clock Sync: No
Serial Interfaces: -
Control Features: Current Limit, Frequency Control, Ramp, Soft Start
Operating Temperature: -40°C ~ 85°C (TA)
Mounting Type: Through Hole
Package / Case: 16-DIP (0.300", 7.62mm)
Supplier Device Package: 16-PDIP
