UG2004PT
Taiwan Semiconductor Corporation
Taiwan Semiconductor Corporation
DIODE ARRAY GP 200V 20A TO247AD
$1.73
Available to order
Reference Price (USD)
1+
$1.73173
500+
$1.7144127
1000+
$1.6970954
1500+
$1.6797781
2000+
$1.6624608
2500+
$1.6451435
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Upgrade your circuitry with the UG2004PT by Taiwan Semiconductor Corporation, a top-tier rectifier diode array from the Diodes - Rectifiers - Arrays subcategory. Engineered for precision and reliability, this component features fast switching and high current capacity, making it perfect for AC/DC conversion and voltage regulation. Common applications include welding machines, battery chargers, and renewable energy systems. With Taiwan Semiconductor Corporation's commitment to quality, the UG2004PT stands out as a robust solution for engineers seeking optimal performance in harsh environments.
Specifications
- Product Status: Active
- Diode Configuration: 1 Pair Common Cathode
- Diode Type: Standard
- Voltage - DC Reverse (Vr) (Max): 200 V
- Current - Average Rectified (Io) (per Diode): 20A
- Voltage - Forward (Vf) (Max) @ If: 930 mV @ 10 A
- Speed: Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr): 25 ns
- Current - Reverse Leakage @ Vr: 200 µA @ 200 V
- Operating Temperature - Junction: -55°C ~ 175°C
- Mounting Type: Through Hole
- Package / Case: TO-247-3
- Supplier Device Package: TO-247AD (TO-3P)
