VS-12FL80S05
Vishay General Semiconductor - Diodes Division
Vishay General Semiconductor - Diodes Division
DIODE GEN PURP 800V 12A DO203AA
$6.25
Available to order
Reference Price (USD)
100+
$5.67820
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The VS-12FL80S05 from Vishay General Semiconductor - Diodes Division is a premium single rectifier diode that stands out in the Diodes - Rectifiers - Single segment. With excellent thermal characteristics and high reverse voltage capability, it is perfect for high-frequency applications like RF modules and wireless charging systems. This diode is also widely used in automotive lighting and HVAC controls, ensuring efficient energy conversion. Vishay General Semiconductor - Diodes Division's dedication to quality means the VS-12FL80S05 meets rigorous standards, providing dependable performance for both commercial and industrial applications.
Specifications
- Product Status: Active
- Diode Type: Standard
- Voltage - DC Reverse (Vr) (Max): 800 V
- Current - Average Rectified (Io): 12A
- Voltage - Forward (Vf) (Max) @ If: 1.4 V @ 12 A
- Speed: Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr): 500 ns
- Current - Reverse Leakage @ Vr: 50 µA @ 800 V
- Capacitance @ Vr, F: -
- Mounting Type: Chassis, Stud Mount
- Package / Case: DO-203AA, DO-4, Stud
- Supplier Device Package: DO-203AA (DO-4)
- Operating Temperature - Junction: -65°C ~ 150°C
