WNS30H100CBJ
WeEn Semiconductors
WeEn Semiconductors
DIODE ARRAY SCHOT 100V 15A D2PAK
$1.12
Available to order
Reference Price (USD)
4,800+
$0.39900
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Introducing WeEn Semiconductors's WNS30H100CBJ, a game-changing diode array in the Discrete Semiconductor Products category. Specifically engineered for high-frequency rectification, this component minimizes switching losses in SMPS and RF circuits. Its hermetically sealed package provides exceptional moisture resistance for outdoor applications like traffic signal systems and railway electronics. Trust WeEn Semiconductors's decades of semiconductor expertise embedded in every WNS30H100CBJ for uncompromising performance.
Specifications
- Product Status: Active
- Diode Configuration: 1 Pair Common Cathode
- Diode Type: Schottky
- Voltage - DC Reverse (Vr) (Max): 100 V
- Current - Average Rectified (Io) (per Diode): 15A
- Voltage - Forward (Vf) (Max) @ If: 710 mV @ 15 A
- Speed: Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr): -
- Current - Reverse Leakage @ Vr: 50 µA @ 100 V
- Operating Temperature - Junction: 150°C (Max)
- Mounting Type: Surface Mount
- Package / Case: TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
- Supplier Device Package: D2PAK
