74LV132BQ,115
Nexperia USA Inc.
Nexperia USA Inc.
IC GATE NAND 4CH 2-INP 14DHVQFN
$0.45
Available to order
Reference Price (USD)
3,000+
$0.16585
6,000+
$0.15515
15,000+
$0.14445
30,000+
$0.13696
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Discover the precision engineering of Nexperia USA Inc.'s 74LV132BQ,115, a standout in our Logic - Gates and Inverters inventory. This integrated circuit offers multiple logic functions in a single package, reducing board space and simplifying circuit design. Key features include Schmitt-trigger inputs for improved signal integrity, balanced propagation delays, and compatibility with TTL logic levels. The 74LV132BQ,115 finds applications in digital signal processing, computer peripherals, and communication systems. From industrial PLCs to consumer electronics like gaming consoles and smart TVs, this logic IC delivers consistent performance. Its RoHS compliance and lead-free construction meet global environmental standards.
Specifications
- Product Status: Active
- Logic Type: NAND Gate
- Number of Circuits: 4
- Number of Inputs: 2
- Features: Schmitt Trigger
- Voltage - Supply: 1V ~ 5.5V
- Current - Quiescent (Max): 40 µA
- Current - Output High, Low: 12mA, 12mA
- Logic Level - Low: 0.3V ~ 1.2V
- Logic Level - High: 1.4V ~ 3.9V
- Max Propagation Delay @ V, Max CL: 9ns @ 5V, 50pF
- Operating Temperature: -40°C ~ 125°C
- Mounting Type: Surface Mount
- Supplier Device Package: 14-DHVQFN (2.5x3)
- Package / Case: 14-VFQFN Exposed Pad
