802-10-056-62-001000
Mill-Max Manufacturing Corp.
Mill-Max Manufacturing Corp.
CONN HEADER VERT 56POS 2.54MM
$12.32
Available to order
Reference Price (USD)
1+
$11.01000
10+
$10.52700
25+
$9.56960
50+
$9.09120
100+
$8.85200
250+
$7.89500
500+
$7.41652
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Discover the 802-10-056-62-001000 rectangular connector header from Mill-Max Manufacturing Corp., a top choice for male pin interconnections. These headers provide exceptional mechanical strength and electrical performance. With options for through-hole or surface mount, the 802-10-056-62-001000 adapts to different assembly processes. Ideal for use in automotive electronics, consumer gadgets, and IoT devices. Mill-Max Manufacturing Corp. guarantees connectors that enhance your product's reliability and efficiency.
Specifications
- Product Status: Active
- Connector Type: Header
- Contact Type: Male Pin
- Pitch - Mating: 0.100" (2.54mm)
- Number of Positions: 56
- Number of Rows: 2
- Row Spacing - Mating: 0.100" (2.54mm)
- Number of Positions Loaded: All
- Style: Board to Board
- Shrouding: Unshrouded
- Mounting Type: Through Hole
- Termination: Press-Fit, Solder
- Fastening Type: Push-Pull
- Contact Length - Mating: 0.191" (4.85mm)
- Contact Length - Post: 0.143" (3.63mm)
- Overall Contact Length: 0.444" (11.28mm)
- Insulation Height: 0.110" (2.79mm)
- Contact Shape: Circular
- Contact Finish - Mating: Gold
- Contact Finish Thickness - Mating: 10.0µin (0.25µm)
- Contact Finish - Post: Gold
- Contact Material: Brass Alloy
- Insulation Material: Polycyclohexylenedimethylene Terephthalate (PCT)
- Features: -
- Operating Temperature: -
- Ingress Protection: -
- Material Flammability Rating: -
- Insulation Color: Black
- Current Rating (Amps): -
- Voltage Rating: -
