803-43-090-20-001000
Mill-Max Manufacturing Corp.
Mill-Max Manufacturing Corp.
CONN RCPT 90POS 0.1 GOLD PCB R/A
$21.29
Available to order
Reference Price (USD)
1+
$19.77000
10+
$18.35600
25+
$16.47320
50+
$16.00260
100+
$14.11990
250+
$13.17860
500+
$12.89620
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The 803-43-090-20-001000 Mill-Max Manufacturing Corp. Rectangular Connectors - Headers, Receptacles, and Female Sockets offer superior connectivity solutions for modern electronics. Designed with versatility in mind, these connectors support high-speed data transfer and power delivery. Their compact design and rugged build make them suitable for aerospace, military, and IoT applications. Whether you need board-to-board, cable-to-board, or wire-to-wire connections, Mill-Max Manufacturing Corp. provides reliable options. Examples include avionics systems, defense equipment, and smart home devices.
Specifications
- Product Status: Active
- Connector Type: Receptacle
- Contact Type: Female Socket
- Style: Board to Board
- Number of Positions: 90
- Number of Positions Loaded: All
- Pitch - Mating: 0.100" (2.54mm)
- Number of Rows: 2
- Row Spacing - Mating: 0.100" (2.54mm)
- Mounting Type: Through Hole, Right Angle
- Termination: Solder
- Fastening Type: Push-Pull
- Contact Finish - Mating: Gold
- Contact Finish Thickness - Mating: 30.0µin (0.76µm)
- Insulation Color: Black
- Insulation Height: 0.200" (5.08mm)
- Contact Length - Post: 0.126" (3.20mm)
- Operating Temperature: -55°C ~ 125°C
- Material Flammability Rating: UL94 V-0
- Contact Finish - Post: Tin
- Mated Stacking Heights: -
- Ingress Protection: -
- Features: -
- Current Rating (Amps): 4.5A
- Voltage Rating: -
