APT30D60BCAG
Microchip Technology
Microchip Technology
DIODE ARRAY GP 600V 27A TO247
$6.07
Available to order
Reference Price (USD)
1+
$7.14000
10+
$6.42600
100+
$5.28360
500+
$4.42680
1,000+
$3.99840
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Power your designs with the APT30D60BCAG diode rectifier array by Microchip Technology, a flagship product in the Diodes - Rectifiers - Arrays subcategory. Featuring dual-diode common cathode/anode configurations, this versatile component excels in voltage doubling circuits and flyback converters. Its lead-free construction meets global environmental standards while maintaining robust performance in appliance controls and HVAC systems. Microchip Technology delivers this industry-leading solution with full traceability and RoHS compliance.
Specifications
- Product Status: Active
- Diode Configuration: 1 Pair Common Anode
- Diode Type: Standard
- Voltage - DC Reverse (Vr) (Max): 600 V
- Current - Average Rectified (Io) (per Diode): 27A
- Voltage - Forward (Vf) (Max) @ If: 1.8 V @ 30 A
- Speed: Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr): 85 ns
- Current - Reverse Leakage @ Vr: 250 µA @ 600 V
- Operating Temperature - Junction: -55°C ~ 150°C
- Mounting Type: Through Hole
- Package / Case: TO-247-3
- Supplier Device Package: TO-247 [B]
