IPB22N03S4L-15
Infineon Technologies
Infineon Technologies
IPB22N03 - 20V-40V N-CHANNEL AUT
$1.13
Available to order
Reference Price (USD)
1+
$1.13000
500+
$1.1187
1000+
$1.1074
1500+
$1.0961
2000+
$1.0848
2500+
$1.0735
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The IPB22N03S4L-15 single MOSFET from Infineon Technologies is a game-changer in power electronics. As part of the Discrete Semiconductor Products family, it offers unparalleled efficiency in energy conversion and management. Key applications include uninterruptible power supplies (UPS), welding equipment, and industrial motor drives. With features like high temperature operation and ESD protection, the IPB22N03S4L-15 is a must-have in the Transistors - FETs, MOSFETs - Single category.
Specifications
- Product Status: Active
- FET Type: N-Channel
- Technology: MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss): 30 V
- Current - Continuous Drain (Id) @ 25°C: 22A (Tc)
- Drive Voltage (Max Rds On, Min Rds On): 4.5V, 10V
- Rds On (Max) @ Id, Vgs: 14.9mOhm @ 22A, 10V
- Vgs(th) (Max) @ Id: 2.2V @ 10µA
- Gate Charge (Qg) (Max) @ Vgs: 14 nC @ 10 V
- Vgs (Max): ±16V
- Input Capacitance (Ciss) (Max) @ Vds: 980 pF @ 25 V
- FET Feature: -
- Power Dissipation (Max): 31W (Tc)
- Operating Temperature: -55°C ~ 175°C (TJ)
- Mounting Type: Surface Mount
- Supplier Device Package: PG-TO263-3-2
- Package / Case: TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
