IRLR3802TRPBF-INF
Infineon Technologies
Infineon Technologies
IRLR3802 - HEXFET POWER MOSFET
$0.00
Available to order
Reference Price (USD)
1+
$0.00000
500+
$0
1000+
$0
1500+
$0
2000+
$0
2500+
$0
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Discover the IRLR3802TRPBF-INF from Infineon Technologies, a high-performance single MOSFET designed for efficient power management in modern electronics. As part of the Discrete Semiconductor Products category, this transistor offers low on-resistance, fast switching speeds, and excellent thermal stability. Ideal for applications such as power supplies, motor control, and LED lighting, the IRLR3802TRPBF-INF ensures reliable performance in demanding environments. Upgrade your circuit designs with Infineon Technologies's cutting-edge technology today.
Specifications
- Product Status: Active
- FET Type: N-Channel
- Technology: MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss): 12 V
- Current - Continuous Drain (Id) @ 25°C: 84A (Tc)
- Drive Voltage (Max Rds On, Min Rds On): 2.8V, 4.5V
- Rds On (Max) @ Id, Vgs: 8.5mOhm @ 15A, 4.5V
- Vgs(th) (Max) @ Id: 1.9V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs: 41 nC @ 5 V
- Vgs (Max): ±12V
- Input Capacitance (Ciss) (Max) @ Vds: 2490 pF @ 6 V
- FET Feature: -
- Power Dissipation (Max): 88W (Tc)
- Operating Temperature: -55°C ~ 175°C (TJ)
- Mounting Type: Surface Mount
- Supplier Device Package: D-Pak
- Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
