IXGH120N30C3
IXYS
IXYS
IGBT 300V 75A 540W TO247
$0.00
Available to order
Reference Price (USD)
30+
$5.81167
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Discover the IXGH120N30C3 Single IGBT transistor by IXYS, a standout in the Discrete Semiconductor Products lineup. This component excels in high-voltage and high-current applications, featuring low conduction losses and excellent switching performance. Perfect for use in welding equipment, UPS systems, and induction heating, the IXGH120N30C3 ensures reliability and efficiency. Its rugged construction and advanced technology make it a top choice for engineers seeking durable and high-performing IGBTs. Upgrade your designs with the IXGH120N30C3 for unmatched power control.
Specifications
- Product Status: Active
- IGBT Type: PT
- Voltage - Collector Emitter Breakdown (Max): 300 V
- Current - Collector (Ic) (Max): 75 A
- Current - Collector Pulsed (Icm): 600 A
- Vce(on) (Max) @ Vge, Ic: 2.1V @ 15V, 120A
- Power - Max: 540 W
- Switching Energy: 230µJ (on), 730µJ (off)
- Input Type: Standard
- Gate Charge: 230 nC
- Td (on/off) @ 25°C: 28ns/109ns
- Test Condition: 200V, 60A, 2Ohm, 15V
- Reverse Recovery Time (trr): -
- Operating Temperature: -55°C ~ 150°C (TJ)
- Mounting Type: Through Hole
- Package / Case: TO-247-3
- Supplier Device Package: TO-247AD
