IXGT20N60BD1
IXYS
IXYS
IGBT 600V 40A 150W TO268
$0.00
Available to order
Reference Price (USD)
1+
$0.00000
500+
$0
1000+
$0
1500+
$0
2000+
$0
2500+
$0
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Upgrade your power management systems with the IXGT20N60BD1 Single IGBT transistor from IXYS. This Discrete Semiconductor Product boasts high current density and excellent thermal conductivity, making it suitable for high-power applications. From railway systems to wind turbines, the IXGT20N60BD1 provides reliable and efficient operation. IXYS's advanced semiconductor technology guarantees a component that excels in performance and durability. Choose IXGT20N60BD1 for your critical power needs.
Specifications
- Product Status: Obsolete
- IGBT Type: -
- Voltage - Collector Emitter Breakdown (Max): 600 V
- Current - Collector (Ic) (Max): 40 A
- Current - Collector Pulsed (Icm): 80 A
- Vce(on) (Max) @ Vge, Ic: 2V @ 15V, 20A
- Power - Max: 150 W
- Switching Energy: 700µJ (off)
- Input Type: Standard
- Gate Charge: 55 nC
- Td (on/off) @ 25°C: 15ns/110ns
- Test Condition: 480V, 20A, 10Ohm, 15V
- Reverse Recovery Time (trr): 25 ns
- Operating Temperature: -55°C ~ 150°C (TJ)
- Mounting Type: Surface Mount
- Package / Case: TO-268-3, D³Pak (2 Leads + Tab), TO-268AA
- Supplier Device Package: TO-268AA
