JANTXV1N3022C-1/TR
Microchip Technology
Microchip Technology
VOLTAGE REGULATOR
$29.42
Available to order
Reference Price (USD)
1+
$29.41500
500+
$29.12085
1000+
$28.8267
1500+
$28.53255
2000+
$28.2384
2500+
$27.94425
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Engineered for excellence, the JANTXV1N3022C-1/TR Zener diode from Microchip Technology is a critical component in the Discrete Semiconductor Products category. This single Zener diode is designed to deliver unmatched voltage regulation, with features such as high surge current capability and low dynamic impedance. It is particularly suited for applications in automotive electronics, where it protects ECUs and sensors from voltage surges. The JANTXV1N3022C-1/TR is also widely used in industrial automation, providing stable voltage references for PLCs and motor drives. Its versatility extends to consumer electronics, where it ensures the longevity of devices like smartphones and laptops by preventing voltage overloads.
Specifications
- Product Status: Active
- Voltage - Zener (Nom) (Vz): 12 V
- Tolerance: ±2%
- Power - Max: 1 W
- Impedance (Max) (Zzt): 9 Ohms
- Current - Reverse Leakage @ Vr: 10 µA @ 9.1 V
- Voltage - Forward (Vf) (Max) @ If: 1.2 V @ 200 mA
- Operating Temperature: -55°C ~ 175°C
- Mounting Type: Through Hole
- Package / Case: DO-204AL, DO-41, Axial
- Supplier Device Package: DO-41
