MM74C08N
Fairchild Semiconductor
Fairchild Semiconductor
AND GATE
$7.96
Available to order
Reference Price (USD)
1+
$7.96000
500+
$7.8804
1000+
$7.8008
1500+
$7.7212
2000+
$7.6416
2500+
$7.562
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The MM74C08N by Fairchild Semiconductor sets new standards in the Logic - Gates and Inverters category of Integrated Circuits. Featuring advanced silicon-gate CMOS technology, this IC delivers superior performance in logic level conversion and signal gating applications. Notable characteristics include symmetrical output drive capability, balanced propagation delays, and 3-state outputs for bus-oriented applications. Electronic designers frequently incorporate this component in data acquisition systems, test equipment, and digital displays. Practical applications range from factory automation to renewable energy systems and telecommunications infrastructure. The MM74C08N's EMC compliance ensures trouble-free integration into complex electronic systems.
Specifications
- Product Status: Active
- Logic Type: AND Gate
- Number of Circuits: 4
- Number of Inputs: 2
- Features: -
- Voltage - Supply: 3V ~ 15V
- Current - Quiescent (Max): -
- Current - Output High, Low: 8mA, 8mA
- Logic Level - Low: 1.5V ~ 2V
- Logic Level - High: 3.5V ~ 8V
- Max Propagation Delay @ V, Max CL: 70ns @ 10V, 50pF
- Operating Temperature: -55°C ~ 125°C
- Mounting Type: Through Hole
- Supplier Device Package: 14-PDIP
- Package / Case: 14-DIP (0.300", 7.62mm)
