STPS10L40CG-TR
STMicroelectronics
STMicroelectronics
DIODE ARRAY SCHOTTKY 40V D2PAK
$1.75
Available to order
Reference Price (USD)
1,000+
$0.59850
2,000+
$0.55860
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The STPS10L40CG-TR from STMicroelectronics sets new benchmarks in the Discrete Semiconductor Products market. This rectifier array incorporates advanced epitaxial growth technology for superior reverse recovery characteristics. Perfect for high-efficiency adapters, induction heating, and plasma cutting equipment, it offers outstanding thermal cycling performance. STMicroelectronics's rigorous quality control ensures the STPS10L40CG-TR maintains consistent parameters across production batches for design-in reliability.
Specifications
- Product Status: Active
- Diode Configuration: 1 Pair Common Cathode
- Diode Type: Schottky
- Voltage - DC Reverse (Vr) (Max): 40 V
- Current - Average Rectified (Io) (per Diode): 5A
- Voltage - Forward (Vf) (Max) @ If: 530 mV @ 5 A
- Speed: Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr): -
- Current - Reverse Leakage @ Vr: 200 µA @ 40 V
- Operating Temperature - Junction: 150°C (Max)
- Mounting Type: Surface Mount
- Package / Case: TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
- Supplier Device Package: D2PAK
