STW120NF10
STMicroelectronics
STMicroelectronics
MOSFET N-CH 100V 110A TO247-3
$6.33
Available to order
Reference Price (USD)
1+
$5.00000
30+
$4.07200
120+
$3.73600
510+
$3.08045
1,020+
$2.64344
2,520+
$2.52579
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Optimize your power electronics with the STW120NF10 single MOSFET from STMicroelectronics. As a key player in the Discrete Semiconductor Products market, this component delivers high voltage tolerance and minimal power loss. Ideal for applications like solar inverters, electric vehicles, and robotics, the STW120NF10 combines cutting-edge technology with STMicroelectronics's renowned craftsmanship. Experience superior performance in the Transistors - FETs, MOSFETs - Single category.
Specifications
- Product Status: Active
- FET Type: N-Channel
- Technology: MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss): 100 V
- Current - Continuous Drain (Id) @ 25°C: 110A (Tc)
- Drive Voltage (Max Rds On, Min Rds On): 10V
- Rds On (Max) @ Id, Vgs: 10.5mOhm @ 60A, 10V
- Vgs(th) (Max) @ Id: 4V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs: 233 nC @ 10 V
- Vgs (Max): ±20V
- Input Capacitance (Ciss) (Max) @ Vds: 5200 pF @ 25 V
- FET Feature: -
- Power Dissipation (Max): 312W (Tc)
- Operating Temperature: -55°C ~ 175°C (TJ)
- Mounting Type: Through Hole
- Supplier Device Package: TO-247-3
- Package / Case: TO-247-3
