SZMMBZ5240BLT1G
onsemi
onsemi
DIODE ZENER 10V 225MW SOT23-3
$0.22
Available to order
Reference Price (USD)
3,000+
$0.03274
6,000+
$0.02964
15,000+
$0.02592
30,000+
$0.02344
75,000+
$0.02096
150,000+
$0.01761
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The SZMMBZ5240BLT1G from onsemi is a high-performance Zener diode designed for precision voltage regulation in various electronic circuits. As part of the Discrete Semiconductor Products category, this single Zener diode offers exceptional stability and reliability, making it ideal for applications requiring consistent voltage reference. Key features include low impedance, sharp breakdown characteristics, and excellent temperature stability. These diodes are widely used in power supplies, voltage clippers, and surge protectors. For instance, the SZMMBZ5240BLT1G is commonly employed in automotive electronics, telecommunications equipment, and industrial control systems to ensure stable voltage levels and protect sensitive components from voltage spikes.
Specifications
- Product Status: Active
- Voltage - Zener (Nom) (Vz): 10 V
- Tolerance: ±5%
- Power - Max: 225 mW
- Impedance (Max) (Zzt): 17 Ohms
- Current - Reverse Leakage @ Vr: 3 µA @ 8 V
- Voltage - Forward (Vf) (Max) @ If: 900 mV @ 10 mA
- Operating Temperature: -65°C ~ 150°C
- Mounting Type: Surface Mount
- Package / Case: TO-236-3, SC-59, SOT-23-3
- Supplier Device Package: SOT-23-3 (TO-236)
