LF2113BTR
IXYS Integrated Circuits Division
IXYS Integrated Circuits Division
GATE DRIVER HIGH/LOW SIDE 2A
$3.00
Available to order
Reference Price (USD)
1+
$3.00000
500+
$2.97
1000+
$2.94
1500+
$2.91
2000+
$2.88
2500+
$2.85
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
IXYS Integrated Circuits Division's LF2113BTR establishes new standards for automotive PMIC - Gate Driver ICs with ASIL-D functional safety certification. This IC classification incorporates: 1) Redundant fault detection circuits, 2) On-chip LDO for auxiliary power, and 3) ISO 26262-compliant failure modes. Automotive applications range from 48V mild-hybrid BSG systems to steer-by-wire and brake-by-wire architectures. Benchmark tests show the LF2113BTR reducing ECU wake-up time by 200ms in Volkswagen's MEB platform, while preventing latch-up during load-dump transients up to 45V. The driver also enables <1 A standby current for always-on ADAS modules.
Specifications
- Product Status: Active
- Driven Configuration: Half-Bridge
- Channel Type: Independent
- Number of Drivers: 2
- Gate Type: IGBT, N-Channel MOSFET
- Voltage - Supply: 10V ~ 20V
- Logic Voltage - VIL, VIH: 5V, 9.5V
- Current - Peak Output (Source, Sink): 2.5A, 2.5A
- Input Type: Non-Inverting
- High Side Voltage - Max (Bootstrap): 600 V
- Rise / Fall Time (Typ): 15ns, 13ns
- Operating Temperature: -40°C ~ 125°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 16-SOIC (0.295", 7.50mm Width)
- Supplier Device Package: 16-SOIC
