NGTB40N120LWG
onsemi
onsemi
IGBT 1200V 40A TO247
$0.00
Available to order
Reference Price (USD)
1+
$0.00000
500+
$0
1000+
$0
1500+
$0
2000+
$0
2500+
$0
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Enhance your electronic projects with the NGTB40N120LWG Single IGBT transistor from onsemi. This Discrete Semiconductor Product offers exceptional performance with low switching losses and high current capacity. Suitable for applications such as medical equipment, aerospace systems, and consumer electronics, the NGTB40N120LWG ensures precision and reliability. onsemi's cutting-edge technology guarantees a component that meets the highest industry standards. Choose NGTB40N120LWG for efficient and durable power solutions.
Specifications
- Product Status: Obsolete
- IGBT Type: Trench Field Stop
- Voltage - Collector Emitter Breakdown (Max): 1200 V
- Current - Collector (Ic) (Max): 80 A
- Current - Collector Pulsed (Icm): 320 A
- Vce(on) (Max) @ Vge, Ic: 2.35V @ 15V, 40A
- Power - Max: 260 W
- Switching Energy: 5.5mJ (on), 1.4mJ (off)
- Input Type: Standard
- Gate Charge: 420 nC
- Td (on/off) @ 25°C: 140ns/360ns
- Test Condition: 600V, 40A, 10Ohm, 15V
- Reverse Recovery Time (trr): -
- Operating Temperature: -55°C ~ 150°C (TJ)
- Mounting Type: Through Hole
- Package / Case: TO-247-3
- Supplier Device Package: TO-247-3
Related Products
Infineon Technologies
IRGSL4B60KD1PBF
Infineon Technologies
IRGPS60B120KDP
Infineon Technologies
IRGIB4630DPBF
Infineon Technologies
IRGP4263D-EPBF
Infineon Technologies
IRG4IBC30W
onsemi
NGB18N40CLBT4
onsemi
FGP5N60UFDTU
Infineon Technologies
IRGB4064DPBF
Infineon Technologies
IHW40N120R3FKSA1
