NX2301PVL
Nexperia USA Inc.
Nexperia USA Inc.
MOSFET P-CHANNEL 20V 2A TO236AB
$0.07
Available to order
Reference Price (USD)
10,000+
$0.06318
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The NX2301PVL single MOSFET from Nexperia USA Inc. is a game-changer in power electronics. As part of the Discrete Semiconductor Products family, it offers unparalleled efficiency in energy conversion and management. Key applications include uninterruptible power supplies (UPS), welding equipment, and industrial motor drives. With features like high temperature operation and ESD protection, the NX2301PVL is a must-have in the Transistors - FETs, MOSFETs - Single category.
Specifications
- Product Status: Active
- FET Type: P-Channel
- Technology: MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss): 20 V
- Current - Continuous Drain (Id) @ 25°C: 2A (Ta)
- Drive Voltage (Max Rds On, Min Rds On): 1.8V, 4.5V
- Rds On (Max) @ Id, Vgs: 120mOhm @ 1A, 4.5V
- Vgs(th) (Max) @ Id: 1.1V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs: 6 nC @ 4.5 V
- Vgs (Max): ±8V
- Input Capacitance (Ciss) (Max) @ Vds: 380 pF @ 6 V
- FET Feature: -
- Power Dissipation (Max): 400mW (Ta)
- Operating Temperature: 150°C (TJ)
- Mounting Type: Surface Mount
- Supplier Device Package: TO-236AB
- Package / Case: TO-236-3, SC-59, SOT-23-3
