VS-GB55NA120UX
Vishay General Semiconductor - Diodes Division
Vishay General Semiconductor - Diodes Division
IGBT MOD 1200V 84A 431W SOT227
$0.00
Available to order
Reference Price (USD)
160+
$29.13325
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Vishay General Semiconductor - Diodes Division's VS-GB55NA120UX sets the benchmark for IGBT modules in the Transistors - IGBTs - Modules sector. This discrete semiconductor product features revolutionary reverse-conducting technology and dual-side cooling capability. The module's competitive advantages include: 50% higher power cycling capability, RoHS-compliant materials, and vibration-resistant construction. It's ideally suited for hybrid electric vehicles, smart grid applications, and high-power RF amplifiers. Implement the VS-GB55NA120UX in your traction inverters or high-energy physics experiments for unparalleled performance. Trust Vishay General Semiconductor - Diodes Division to deliver cutting-edge IGBT solutions with the VS-GB55NA120UX power module.
Specifications
- Product Status: Obsolete
- IGBT Type: NPT
- Configuration: Single
- Voltage - Collector Emitter Breakdown (Max): 1200 V
- Current - Collector (Ic) (Max): 84 A
- Power - Max: 431 W
- Vce(on) (Max) @ Vge, Ic: -
- Current - Collector Cutoff (Max): 50 µA
- Input Capacitance (Cies) @ Vce: -
- Input: Standard
- NTC Thermistor: No
- Operating Temperature: -40°C ~ 150°C (TJ)
- Mounting Type: Chassis Mount
- Package / Case: SOT-227-4, miniBLOC
- Supplier Device Package: SOT-227
