VS-CPV363M4UPBF
Vishay General Semiconductor - Diodes Division
Vishay General Semiconductor - Diodes Division
IGBT MODULE 600V 13A 36W IMS-2
$0.00
Available to order
Reference Price (USD)
160+
$31.26913
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Experience next-generation power control with Vishay General Semiconductor - Diodes Division's VS-CPV363M4UPBF IGBT module. As a leader in Discrete Semiconductor Products, this transistor module features state-of-the-art trench gate technology and advanced carrier lifetime control. The VS-CPV363M4UPBF offers: symmetrical blocking capability, low switching losses, and excellent cosmic ray robustness. Target applications include electric bus charging infrastructure, industrial plasma generators, and high-power laser drivers. Implement the VS-CPV363M4UPBF in your next-generation HVDC systems or particle accelerator power supplies. Vishay General Semiconductor - Diodes Division delivers reliability where it matters most with the VS-CPV363M4UPBF IGBT module.
Specifications
- Product Status: Obsolete
- IGBT Type: -
- Configuration: -
- Voltage - Collector Emitter Breakdown (Max): 600 V
- Current - Collector (Ic) (Max): 13 A
- Power - Max: 36 W
- Vce(on) (Max) @ Vge, Ic: 2.2V @ 15V, 6.8A
- Current - Collector Cutoff (Max): 250 µA
- Input Capacitance (Cies) @ Vce: 1.1 nF @ 30 V
- Input: Standard
- NTC Thermistor: No
- Operating Temperature: -40°C ~ 150°C (TJ)
- Mounting Type: Through Hole
- Package / Case: 19-SIP (13 Leads), IMS-2
- Supplier Device Package: IMS-2
