PMIC - Voltage Reference
PMIC - Voltage Reference: Precision Power Management Components
Definition & Functionality
PMIC - Voltage References are specialized integrated circuits (ICs) within the Power Management IC (PMIC) category, designed to generate a stable, precise DC voltage regardless of variations in input voltage, load conditions, or temperature. These components serve as critical "voltage standards" for analog and mixed-signal circuits, ensuring accuracy in applications like data converters, sensors, and power supplies.
Types & Key Variations
1. Series Voltage References: Provide a fixed output with low dropout voltage, ideal for battery-powered devices.
2. Shunt Voltage References: Operate like precision Zener diodes, suited for high-accuracy, low-current systems.
3. Adjustable Voltage References: Allow output customization via external resistors, offering design flexibility.
4. Bandgap References: Leverage semiconductor bandgap properties for ultra-stable outputs across temperature ranges.
5. Buried Zener References: Deliver the highest precision (e.g., 0.04%) for metrology or medical equipment.
Selection Guidelines
- Accuracy & Tolerance: Prioritize < 1% tolerance for precision systems (e.g., ADCs).
- Temperature Coefficient (TempCo): Choose <10ppm/ C for environments with thermal fluctuations.
- Noise Performance: Opt for low-noise (<10 Vpp) designs in sensitive analog circuits.
- Package & Power: Match SOT-23 (portable) or SOIC (industrial) packages to your PCB constraints.
- Long-Term Stability: Critical for automotive/industrial apps; verify datasheet aging specs (e.g., 50ppm/1000hr).
Why It Matters
Voltage References are the unsung heroes of reliable electronics, minimizing drift and noise in power rails. From IoT sensor calibration to aerospace systems, selecting the right type ensures optimal performance and longevity. Partner with trusted suppliers (e.g., Texas Instruments, Analog Devices) to source certified components with traceable quality data.
Filter and sort
Categories
MAX6192BESA+T
IC VREF SERIES 0.2% 8SOIC
LT6650HS5#TRPBF
IC VREF SERIES 1.5% TSOT23-5
LM4040BIX3-5.0-T
PRECISION MICROPOWER SHUNT VREF
ADR431AR-REEL7
IC VREF SERIES 2.5V 8-SOIC
TLVH431BCLPE3
IC VREF SHUNT PREC ADJ TO-92-3
TLVH431IDBZR
IC VREF SHUNT ADJ 1.5% SOT23-3
MAX6126B21+
IC VREF SERIES 0.1% 8UMAX
LT1461ACS8-3.3#TRPBF
IC VREF SERIES 0.04% 8SOIC
TL431IYDT
IC VREF SHUNT ADJ 2.21% 8SO
LT6656AIS6-3.3#TRMPBF
IC VREF SERIES 0.05% TSOT23-6
LM4040AEX3-3.0/V+T
IC VREF SHUNT 0.1% SC70-3
LM385MX/NOPB
IC VREF SHUNT ADJ 2% 8SOIC
TL432ACDBZT
IC VREF SHUNT ADJ 1% SOT23-3
MAX6225AESA+
IC VREF SERIES 0.04% 8SOIC
TL431BSA-7
IC VREF SHUNT ADJ 0.5% SOT23-3
ISL21080DIH310Z-TK
IC VREF SERIES 0.7% SOT23-3
LM4132DMF-2.0/NOPB
IC VREF SERIES 0.4% SOT23-5
LT1004IZ-2.5#PBF
IC VREF SHUNT 0.8% TO92-3
LM4050QBEM3-2.5/NOPB
IC VREF SHUNT 0.2% SOT23-3
LM431AIMX
IC VREF SHUNT ADJ 2% 8SOIC
