APT75GP120B2G
Microchip Technology
Microchip Technology
IGBT 1200V 100A 1042W TMAX
$27.05
Available to order
Reference Price (USD)
1+
$27.42000
10+
$25.36100
25+
$23.30480
100+
$21.65990
250+
$19.87776
500+
$18.91814
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The APT75GP120B2G by Microchip Technology is a high-efficiency Single IGBT transistor, part of the esteemed Discrete Semiconductor Products line. With low on-state voltage and high-speed switching, it is ideal for energy-saving applications. Commonly used in electric vehicles, smart grids, and industrial machinery, the APT75GP120B2G delivers robust performance. Microchip Technology's commitment to quality ensures a product that meets the rigorous demands of modern electronics. Integrate APT75GP120B2G into your designs for optimal power control.
Specifications
- Product Status: Active
- IGBT Type: PT
- Voltage - Collector Emitter Breakdown (Max): 1200 V
- Current - Collector (Ic) (Max): 100 A
- Current - Collector Pulsed (Icm): 300 A
- Vce(on) (Max) @ Vge, Ic: 3.9V @ 15V, 75A
- Power - Max: 1042 W
- Switching Energy: 1620µJ (on), 2500µJ (off)
- Input Type: Standard
- Gate Charge: 320 nC
- Td (on/off) @ 25°C: 20ns/163ns
- Test Condition: 600V, 75A, 5Ohm, 15V
- Reverse Recovery Time (trr): -
- Operating Temperature: -55°C ~ 150°C (TJ)
- Mounting Type: Through Hole
- Package / Case: TO-247-3 Variant
- Supplier Device Package: -
