CPV363M4F
Vishay General Semiconductor - Diodes Division
Vishay General Semiconductor - Diodes Division
IGBT MODULE 600V 16A 36W IMS-2
$0.00
Available to order
Reference Price (USD)
1+
$0.00000
500+
$0
1000+
$0
1500+
$0
2000+
$0
2500+
$0
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The CPV363M4F by Vishay General Semiconductor - Diodes Division redefines performance in the IGBT modules segment of Discrete Semiconductor Products. Featuring sixth-generation field-stop technology, this power transistor delivers optimal switching characteristics and short-circuit withstand capability. Key attributes include: 175 C maximum junction temperature, low EMI generation, and integrated current sensing. Industrial applications span from elevator drives and CNC machinery to large-scale HVAC systems. A practical implementation would be using the CPV363M4F in high-efficiency servo controllers for manufacturing automation. Vishay General Semiconductor - Diodes Division combines innovation with quality in every CPV363M4F module.
Specifications
- Product Status: Obsolete
- IGBT Type: -
- Configuration: Three Phase Inverter
- Voltage - Collector Emitter Breakdown (Max): 600 V
- Current - Collector (Ic) (Max): 16 A
- Power - Max: 36 W
- Vce(on) (Max) @ Vge, Ic: 1.63V @ 15V, 16A
- Current - Collector Cutoff (Max): 250 µA
- Input Capacitance (Cies) @ Vce: 1.1 nF @ 30 V
- Input: Standard
- NTC Thermistor: No
- Operating Temperature: -40°C ~ 150°C (TJ)
- Mounting Type: Through Hole
- Package / Case: 19-SIP (13 Leads), IMS-2
- Supplier Device Package: IMS-2
