IRG4PH30K
Infineon Technologies
Infineon Technologies
IGBT 1200V 20A 100W TO247AC
$0.00
Available to order
Reference Price (USD)
175+
$3.17160
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The IRG4PH30K by Infineon Technologies is a high-efficiency Single IGBT transistor, part of the esteemed Discrete Semiconductor Products line. With low on-state voltage and high-speed switching, it is ideal for energy-saving applications. Commonly used in electric vehicles, smart grids, and industrial machinery, the IRG4PH30K delivers robust performance. Infineon Technologies's commitment to quality ensures a product that meets the rigorous demands of modern electronics. Integrate IRG4PH30K into your designs for optimal power control.
Specifications
- Product Status: Obsolete
- IGBT Type: -
- Voltage - Collector Emitter Breakdown (Max): 1200 V
- Current - Collector (Ic) (Max): 20 A
- Current - Collector Pulsed (Icm): 40 A
- Vce(on) (Max) @ Vge, Ic: 4.2V @ 15V, 10A
- Power - Max: 100 W
- Switching Energy: 640µJ (on), 920µJ (off)
- Input Type: Standard
- Gate Charge: 53 nC
- Td (on/off) @ 25°C: 28ns/200ns
- Test Condition: 960V, 10A, 23Ohm, 15V
- Reverse Recovery Time (trr): -
- Operating Temperature: -55°C ~ 150°C (TJ)
- Mounting Type: Through Hole
- Package / Case: TO-247-3
- Supplier Device Package: TO-247AC
