STGW30N90D
STMicroelectronics
STMicroelectronics
IGBT 900V 60A 220W TO247
$0.00
Available to order
Reference Price (USD)
1+
$0.00000
500+
$0
1000+
$0
1500+
$0
2000+
$0
2500+
$0
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The STGW30N90D Single IGBT transistor by STMicroelectronics is a versatile component in the Discrete Semiconductor Products range. Designed for efficiency and durability, it features high voltage tolerance and minimal power dissipation. Ideal for use in automotive electronics, HVAC systems, and power tools, the STGW30N90D provides consistent performance in varied conditions. Rely on STMicroelectronics's innovation to power your next-generation devices with this high-quality IGBT.
Specifications
- Product Status: Obsolete
- IGBT Type: -
- Voltage - Collector Emitter Breakdown (Max): 900 V
- Current - Collector (Ic) (Max): 60 A
- Current - Collector Pulsed (Icm): 135 A
- Vce(on) (Max) @ Vge, Ic: 2.75V @ 15V, 20A
- Power - Max: 220 W
- Switching Energy: 1.66mJ (on), 4.44mJ (off)
- Input Type: Standard
- Gate Charge: 110 nC
- Td (on/off) @ 25°C: 29ns/275ns
- Test Condition: 900V, 20A, 10Ohm, 15V
- Reverse Recovery Time (trr): 152 ns
- Operating Temperature: -55°C ~ 150°C (TJ)
- Mounting Type: Through Hole
- Package / Case: TO-247-3
- Supplier Device Package: TO-247-3
