1. Definition of Magnetic Wire Connectors
Terminals - Magnetic Wire Connectors are specialized electrical components designed to establish secure, low-resistance connections for magnet wire (enameled wire) in high-performance applications. These connectors feature precision-engineered terminals that pierce or displace the wire's insulation, ensuring reliable conductivity without stripping. Commonly used in transformers, motors, solenoids, and inductors, they excel in environments demanding vibration resistance, compact spacing, and efficient power transmission.
2. Types of Magnetic Wire Connectors
This category includes several key variants:
- Insulation Displacement Connectors (IDC): Slotted terminals that cut through enamel insulation for gas-tight connections.
- Crimp Terminals: Pre-insulated or bare metal sleeves crimped onto stripped magnet wire.
- PCB Mount Connectors: Board-mounted terminals for direct magnet wire attachment.
- Quick-Connect Terminals: Tool-free designs for rapid assembly.
Materials range from phosphor bronze (for high conductivity) to nickel-plated steel (for durability), with voltage ratings spanning 300V to 1kV+.
3. Purchasing Recommendations
When selecting Magnetic Wire Connectors, consider:
- Wire Gauge Compatibility: Match terminal size (e.g., 18-22 AWG) to your wire diameter.
- Current Rating: Ensure the connector meets or exceeds the application s amperage needs.
- Environmental Factors: Opt for heat-resistant or waterproof designs if exposed to extreme conditions.
- Certifications: Look for UL, IEC, or RoHS compliance for safety and regulatory adherence.
For automated production, IDC types reduce labor costs, while hand-assembled projects may favor crimp terminals. Partner with trusted suppliers to avoid counterfeit components in critical circuits.
Note: Always verify datasheets for thermal cycling performance and termination torque specifications.
Filter and sort
Categories
1247003-3
MAGMATE "300 SERIES" WITH MULTIS
1247003-2
CONN MAG TERM 19-23AWG PRESS-FIT
63883-1
CONN MAG TERM 13-14AWG QC 0.250
63063-2
CONN MAG TERM 22-25AWG QC 0.110
63666-1
CONN MAG TERM 15-16AWG QC 0.187
1601108-1
CONN MAG TERM 18-34AWG IDC
1217406-1
CONN MAG TERM 16-20AWG POKE-IN
62606-1
CONN MAG TERM 30-38AWG POKE-IN
1599105-1
CONN MAG TERM 18-22AWG CRIMP
4-1601028-2
CONN MAG TERM 18-34AWG QC 0.250
1601137-2
CONN MAG TERM 15-23AWG IDC
62898-1
CONN MAG TERM 18-22AWG TAB
1217641-1
CONN MAG TERM 25-27AWG PCB
1601155-3
CONN MAG TERM 29AWG PCB
1534686-1
CONN MAG TERM 23-26AWG PCB
63777-1
CONN MAG TERM 27-30AWG QC 0.110
62131-3
CONN MAG TERM 16-18AWG CRIMP
1534685-1
CONN MAG TERM 26-30AWG PCB
42192-2
CONN MAG TERM 600-3000CMA CRIMP
2-1601117-1
CONN MAG TERM 27-36AWG IDC
